Advanced Upright Microscope System for Brightfield & Fluorescence Imaging

EXL Advanced Upright Microscope System for Brightfield & Fluorescence Imaging

Engineered for advanced research and routine laboratory work, this upright microscope system delivers precision, flexibility, and upgradeability. Designed with modular architecture and seamless integration, it supports Brightfield, Fluorescence, and future enhancements including Darkfield, DIC, and Phase Contrast. The system is ideal for biomedical, life sciences, and materials applications.

Microscope Body & System Integratio

• Modular Upright Frame: High-stability microscope frame supports Brightfield and Fluorescence imaging as standard. Fully upgradeable to Darkfield, Differential Interference Contrast (DIC), Phase Contrast, and multi-head teaching configurations (up to Deca-head).
• Integrated System Components: Microscope, LED Fluorescence Illumination, and Imaging Software/Camera are all from the same manufacturer for optimal compatibility and performance
• Status Display Window: On-body display provides real-time system status and illumination intensity information.

Illumination

• Transmitted Illumination: High-performance white light LED (5W) with a long lifespan of 1,00,000 hours. Integrated Fly-Eye lens design ensures uniform illumination across the entire field of view.

Smart Illumination Control:

• Auto-adjusts transmitted light intensity based on selected objective magnification.
• Sleep mode feature allows auto shut-off after a user-defined period of inactivity to conserve energy and extend lifespan.

Objectives (Bright Field and Fluorescence Compatible)
• Plan Achromat 4X (N.A. 0.10)
• Plan Achromat 10X (N.A. 0.25)
• Plan Fluor 20X (N.A. 0.50)
• Plan Fluor 40X (N.A. 0.75)
• Plan Fluor 100X (N.A. 1.25)
Objective optical graph provided for performance verification.

Nosepiece

• Reversed Sextuple: Accommodates 6 objectives with built-in analyzer slot.
• Smart Recognition: Automatically identifies objective magnification and adjusts illumination intensity accordingly. Enables real-time scale bar calibration for precise measurement and imaging.

Optics and Viewing
TrinocularViewingTube:

• Wide Field of View (FOV) 25 mm.
• Adjustable light path distribution (100:0 / 50:50 / 0:100).
• High-eyepoint 10x eyepieces (25 mm FOV ), both with diopter adjustment.

Mechanical Stage:

• Smooth-operating coaxial control.
  • Double slide holder for simultaneous comparison.

Condenser

Universal Condenser: Optimized for Brightfield and Fluorescence observation. Supports high-contrast imaging.

Fluorescence Module

Turret-Type Fluorescence Attachment:

• Accommodates four filter cubes for quick switching
• LED-based Fluorescence Illumination Unit (same make as microscope) ensures consistent integration.
• Long-life LEDs (25,000 hours) with software control for precision operation.
• Pre-installed Fluorescence Filter Sets: DAPI, FITC, TRITC.
