Description
SYSTEM OVERVIEW
A reliable refrigerated microcentrifuge designed for high-speed performance, precise temperature control, and maximum user convenience. Features a brushless motor, metallic autoclave-resistant rotors, QuickLock lid system, aerosol-tight certification, and advanced functions for short-spin protocols, energy efficiency, and quiet laboratory operation.
KEY FEATURES & BENEFITS
High-Speed Performance
- Maximum speed: 15,060 rpm / 21,300 × g
- Brushless motor for reliable, maintenance-friendly operation
- User-defined RPM or RCF setting
Precise Temperature Control
- Temperature range: –10 °C to +40 °C
- Maintains 4 °C even at maximum speed
- Fast temperature function for rapid cooling
- In-built condensate drain prevents water accumulation in the stainless-steel rotor chamber and avoids corrosion
Flexible Capacity & Rotor Options
- Maximum capacity: 10 × 5 mL tubes
- Supports both fixed-angle and swing-bucket rotors
- Adapters available for 0.2 mL and 0.5 mL tubes
- Optional rotor for 18 × spin-column kits
Rotor Safety & Convenience
- Metallic rotors and lids (withstand autoclaving at 121 °C for 20 min)
- QuickLock system for secure and easy lid closing/opening
- Aerosol-tight rotors certified by third-party agency
- Can be operated with or without rotor lid
Smart Operation Features
- Timer: 10 sec to 9:59 h + continuous run
- Timer starts only when set RPM is reached (ideal for short-spin protocols)
- Dedicated short-spin key with defined maximum speed
- Soft acceleration and deceleration function for gentle sedimentation
- Finished-time function indicates time since centrifugation completed
- Automatic compressor shut-off to reduce energy consumption and extend compressor life
User Comfort & Safety
- Quiet operation: noise level < 54 dB(A)
- Bright digital LCD display
- Emergency lid opening located on the front side
- USB port for service and maintenance
- European CE Certified
ROTOR SPECIFICATIONS
| Rotor Type | Capacity | Max. Speed | Max. RCF | Lid Type | Material |
| Fixed-angle | 24 × 1.5/2.0 mL | 15,060 rpm | 21,300 × g | Aerosol-tight | Metal (rotor + lid) |
| Fixed-angle | 10 × 5 mL | 15,060 rpm | 21,300 × g | Aerosol-tight | Metal (rotor + lid) |
| Optional | 18 × spin-column kits | — | — | Safe centrifugation | — |
TECHNICAL HIGHLIGHTS SUMMARY
- Max. speed / RCF: 15,060 rpm / 21,300 × g
- Temperature range: –10 °C to +40 °C (maintains 4 °C at max speed)
- Capacity: up to 10 × 5 mL or 24 × 1.5/2.0 mL
- Metallic, autoclave-resistant rotors with QuickLock lids
- Third-party certified aerosol tightness
- Fast cool-down + condensate drain
- Soft start/stop + short-spin key
- Timer starts only at set speed
- Noise level < 54 dB(A)
- Front emergency lid release
- LCD display + USB service port
- European CE Certified
