Description
Technical Specification Table
| Specification | Details |
|---|---|
| Eye-Piece | Wide-field 10X or set of 10X & 15X Huygenian |
| Nosepiece | Triplet revolving nosepiece with click stops |
| Stage | High-quality stainless steel stage with slide clips |
| Focusing | Vertical movement of observation tube; coarse by rack-pinion, fine by screw-lever |
| Condenser | Abbe condenser NA 1.25, iris diaphragm, swing-out filter holder |
| Illuminator | Arc-reflector for natural light |
| Objectives | Achromatic 10X and 45X |
| Packing | Styrofoam box or wooden cabinet with lock (on demand) |
| Accessories | Vinyl dust cover, operating manual |
Key Features
• Wide-field 10X eyepiece or optional 10X & 15X Huygenian eyepieces
• Triplet revolving nosepiece with click stops for easy objective change
• High-quality stainless steel stage with slide clips
• Coarse and fine focusing via vertical observation tube movement
• Rack-pinion coarse adjustment and screw-lever fine motion
• Abbe condenser NA 1.25 with iris diaphragm and swing-out filter holder
• Arc-reflector set for using natural light
• Achromatic objectives 10X and 45X for clear magnification
• Robust student-friendly design
• Packed in styrofoam box or optional wooden cabinet with lock
• Accessories include vinyl dust cover and operating manual
Working Principle
The BM–3 microscope directs light from the arc-reflector through the condenser and onto the specimen. The objectives magnify the sample, and the wide-field eyepiece enlarges it for observation. Users adjust focus using coarse and fine knobs while moving the slide on the stage. The Abbe condenser and iris diaphragm control light and contrast, producing clear, bright, and accurate images suitable for student learning and laboratory experiments.
Use Cases
• School and college biology labs for teaching students
• Educational demonstrations of cells, tissues, and microorganisms
• Student practical sessions in microscopy techniques
• Training laboratories for beginners in scientific observation
• Home study or hobbyist microscopy practice
