Description
BINOCULAR LABORATORY MICROSCOPE
Optical System
The offered microscope is equipped with a high-performance binocular viewing system designed for clinical, laboratory, educational, and research applications.
- Binocular head fitted with hard-coated prism system
- Focusable graduated eyepieces for precise viewing adjustment
- Wide Field 10X / 18 mm DIN standard eyepieces
- Multi-lens optical construction for superior image clarity
- All optical components treated with hard-coated anti-fungal coating
- Head inclined at 45° for ergonomic observation
- Smooth 360° rotatable binocular head mounted on precision ball bearings
- Inter-pupillary distance adjustable from 54 mm to 74 mm through sideways movement
Mechanical Construction
The microscope is designed with a robust, laboratory-grade structure ensuring stability, durability, and smooth operation.
- Single mould sturdy stand with anti-rust epoxy powder coating
- Extended base for enhanced operational stability
- Quadruple revolving nosepiece with precise click-stop positioning
- DIN PLAN Achromatic Objectives:
- 4X
- 10X
- 40X
- 100X Oil Immersion
- Objectives are parfocal, self-centered, and anti-fungal coated
Stage & Specimen Handling
- Co-axial mechanical stage: 135 × 125 mm
- Smooth X–Y movement mechanism
- Slide holder size: 75 × 50 mm
- Precision specimen positioning for accurate examination
Condenser & Illumination
The microscope incorporates an efficient illumination system for bright and uniform field visibility.
- 1.25 N.A. Abbe Condenser
- Iris diaphragm with blue filter
- Rack & pinion condenser movement mechanism
- High-efficiency 3W LED illumination
- Rechargeable battery backup for approximately 2–3 hours operation
- Stable constant power illumination system
Focusing Mechanism
- Co-axial coarse and fine focusing controls
- Smooth ball drive focusing system
- Precision movement for accurate focusing at all magnifications
Electrical Specifications
- Operating Voltage: 220–240V AC
- Power Supply Compatibility: 230V ±15%
- Frequency: 50Hz ±3%
Standard Accessories Supplied
- Styrofoam protective packing
- Instruction manual
- Basic maintenance tools
- Dust cover
- Cleaning cloth
- Power cord
- Spare fuses
Warranty
- 3 Years Comprehensive Warranty
